Product Finder by KENDRION

Reliable, quiet and intelligent

Motorized door lock as a high-tech locking system

As a manufacturer of high-tech locking systems, KENDRION has achieved a very reliable motorized door lock with many different locking applications.

The motorized door lock combines a high-power motor driven lock, positional sensing, mechanical locking and control electronics all-in-one. One of the features is closing the door with an adjustable continuous force, which extends the lifetime of the door seals. The lock is self-adjusting to maintain the seal characteristics and offers a big range for different end positions.

Application example industrial baking ovens

It features a ventilation system - useful for applications such as industrial baking ovens:

  • The lock has the capability to vent the oven during the opening and closing process
  • In this position, the hot steam can escape preventing the operator from getting burned



The following safety aspects are considered in our lock: Protection of the operator while locking the door, protection of the door mechanism against damage, EMC-protection, overload fuse.



Benefits at a glance

  • Large stroke range
  • Multiple switching positions
  • High closing forces
  • Optional torque control
  • Fully-automated multi positioning
  • Manual emergency unlocking
  • High-quality sound perception

Technical Data

Parameter Value
Travel 40 mm
Speed 6.5 mm/s
Sensors 6 x positional sensors (open collector 30mA), 1 x microswitch
Maximum closing force 400 N
Voltage supply 24 V DC
Power 19 W (@ 24 V DC)
Operating temperature 0 °C...+80 °C
Housing Polyamide
Dimensions (W x H x D) 117 x 227 x 30 mm

Downloads

Motorized door lock
pdf - 280 KB
Datasheets
Overview locking line
pdf - 161 KB
Operating instructions
Instruction manual | Solenoid Lock HS7722
pdf - 2 MB
Brochures and Flyers, Datasheets
Digital Brochure | Locking Line: Products and Applications
pdf - 11 MB
The motorised door lock - Watch the video now and learn how it works!
