Permanent Magnet Brake - Slim PM Line
SP 61107P00-0001
The permanent magnet brakes of the Slim PM Line were developed specifically for low- and mid-torque servo motors and complement the High Torque Line for applications requiring higher torques. Thanks to the identical interface between the two lines, designers benefit from maximum flexibility — without any need to modify the motor design. With its exceptionally slim design and high cost-efficiency, the Slim PM Line offers the ideal fail-safe solution for compact servo drives.
Technical details
| Description | Value |
|---|---|
| Brake size | 07 |
| Torque | 6.5 Nm |
| Torque definition | M4 (static) |
| Operation mode | Holding Brake |
| Nominal voltage | 24 V |
| Nominal power | 15 W |
| Max. switching energy per ES | 600 J |
| Number of emergency stops | 500 |
| Total work | 300 kJ |
| Temperature range | -40°C...120°C |
| Max. rotation speed (depending on max. switching work during emergency stop) | 10000 min-1 |
| E-Stop rotation speed | 3000 min-1 |
| Backlash | 0° |
| Thermal class | F |
| IP Protection class | IP00 |
| Brake type | P00 |
| Armature type | 800 |
| Hub type | - |
| Hand release | - |
| Counter friction part | - |
| PWM control | possible |
| Outer diameter | 72 mm |
| Lenght | 35.2 mm |
| Hub diameter | 20.2 mm |
| Keyway | - |
| Pitch circle front side | 54 mm |
| Product Line | Slim PM Line |
| Brake technology | Permanent Magnet Brake |
