Kuhnke FIO
DO16 0,5A
694 452 01
The digital Kuhnke FIO I / O modules relay the binary control signals to the actuators. The Kuhnke FIO DO16 module has 16 outputs, each output can be loaded with up to 0.5A. The primary and secondary sides of the module are separated by optocouplers. This galvanic decoupling makes it possible to switch off the supply of the outputs via only one safety component. The signal status of each channel is indicated by LEDs. The generation of a variant that supports distributed clocks is possible on request.
- 16 short-circuit-proof outputs with output current up to 0.5 A
- Status display locally assigned to the terminal point
- Fast connection via connector with PUSH-IN spring connection
Technical details
| Description | Value |
|---|---|
| Function | Digital OUT |
| Model | Control cabinet modul |
| Digital I/Os (integrated) | outputs: 16 DO 0.5A |
| Product status | Standard product |
| Field bus interfaces | EtherCAT |
| Type of connection | female plug with PUSH IN spring connection |
| Status indication | LEDs allocated to the point of termination |
| Housing material | Aluminium frame, plastic housing |
| Dimensions (W x H x D) | 25 x 120 x 90 mm |
| IP-Protection Class | IP 20 |
| Supply voltage | 24 V DC (-15% ... +20%) |
| Operating temperature | 0 ... +55°C |
| Immunity | Zone B according to EN 61131-2 |
| Certifications | CE, UL |
