Electromagnetic Vibration Generator OAB513001
25070001
The compact electromagnetic vibration generator OAB are used for vibrating and dosing in automated processes. The magnet body, made of two ring shells enclosing the excitation winding, is firmly attached to the base. The armature, equipped with two oppositely polarized permanent magnets, is mounted by leaf springs and pre-magnetized. When AC voltage is applied, opposite poles attract, generating an arc-shaped oscillation. The built-in permanent magnets also provide a braking effect that prevents after-vibration when switched off.
Technical details
| Description | Value |
|---|---|
| Nominal voltage | 230 V |
| Apparent Power | 21 VA |
| Nominal air gap | 4.5 mm |
| Oscillating frequency | 3000 rpm |
| Thermal class | E 120 |
| Connection | Clamp |
| Area of application | Vibration and shaking |
