Pressure Switch on Subplate (adjustable, 0.5-4 bar, max. 4 A)
60.073.40.60
The simple and compact design of this adjustable PE converter allows its use in various applications such as medical technology, dental treatment units, robotics, analysis systems, process and safety engineering. Easy mounting and high functional reliability are other advantages. By using silver contacts a long lifetime can be ensured even at high switching frequencies.
Technical details
| Description | Value |
|---|---|
| Product type | PE-converter |
| Mounting | Subplate |
| Pressure range | 0.5 - 4 bar |
| Medium | non-aggressive media |
| Type of electric connection | Connector / flat connection |
| Type of pneumatic connection | M5 |
| Ambient temperature | -0 ... +60 °C |
| Materials | Housing: plastic, seal: FKM |
