Our INTORQ BFK457
Do you need a spring-applied brake that reliably fulfills your desired basic functionality and can quickly be put to work? Then the BFK457 is the perfect match! The integrated fastening screws and fixed air gap ensure that it is easy to install. Its compact design helps to reduce costs and minimize installation space.
Technical Details
Version | INTORQ BFK457 Basic | INTORQ BFK457 Compact | INTORQ BFK457 Double |
---|---|---|---|
Braking torque range | 4 Nm to 80 Nm | 4 Nm to 125 Nm | 2x4 Nm to 2x125 Nm |
Voltages sizes | 24 V to 205 V | 24 V to 205 V | 24 V to 205 V |
Insulation class | F (155°C) | F (155°C) | F (155°C) |
Protection class | IP00 – IP55 | IP00 – IP55 | IP00 – IP55 |
Brochures and Flyers
Brochure | INTORQ BFK457 | Spring-applied brake
pdf - 2 MB
Operating instructions
Operating instruction | INTORQ BFK457
pdf - 2 MB
CAD Files
3D-Models | INTORQ BFK457
zip - 5 MB
Datasheets
Datasheet | Protection ratings | INTORQ BFK457
pdf - 219 KB
Certificates
Certificate of Compliance | UL | INTORQ BFK457
pdf - 200 KB
Certificates
Certificate of Compliance | CSA | INTORQ BFK457
pdf - 180 KB
