CIO CANopen book size
16DI/16DO
611 300 00
The Kuhnke CIO compact I / O connects various input and output signals in a compact housing in Book size format. The process data of the PLC are made available via the CANopen interface according to the device profile CiA 401. The robust design makes it suitable for use in machine and apparatus engineering.
- Robust housing in booksize format
- integrated I/Os: 16DI/16DO
- CANopen fieldbus interface
Technical details
| Description | Value |
|---|---|
| Configuration | 16DI/16DO |
| Function | I/O system with CANopen field bus |
| Model | Control cabinet modul |
| Product status | Special edition |
| Field bus interfaces | CANopen |
| Interfaces | CANopen‑Node |
| Digital I/Os (integrated) | 16 DI 5ms / 16 DO 0,5A |
| Type of connection | multi-pin plug connector |
| Status indication | system messages, I/O status |
| Housing material | stainless steel |
| Dimensions (W x H x D) | 160 mm x 30 mm x 100 mm |
| IP-Protection Class | IP 20 |
| Supply voltage | 24 V (-20% / +25%) |
| Operating temperature | 0 ... +55 °C |
