OR Unit (also shuttle valve)
47.003
Kendrion has developed a high-quality range of non-return valves for applications requiring non-return and check functions. The outlet restrictor is used for regulating the speed of cylinders and can be screwed directly into the exhaust ports of miniature valves with M5 thread.
Technical details
| Description | Value |
|---|---|
| Pressure range | 0 - 8 bar |
| Nominal orifice | 2 mm |
| Medium | Filtered (5 µm), lubricated or non lubricated air |
| Type of pneumatic connection | M5 |
| Valve type | Check valves and flow regulators |
| Ambient temperature | -10 ... +70 °C |
| Materials | Housing: Al, seal: NBR |
