Engineering Software & Tools
Software Engineering based on CODESYS
Kendrion uses CODESYS, a software platform for many tasks in automation technology. The basis is the standard IEC 61131-3 programming system. Additional tools and tailored functions simplify software engineering in mechanical and apparatus engineering with CODESYS and provide new approaches to solutions.
Products
(13)
show results as grid
show results as list
|
Title
ascending
descending
|
Type
ascending
descending
|
Integrated function
ascending
descending
|
Product status
ascending
descending
|
Application
ascending
descending
|
Provision
ascending
descending
|
Requirements
ascending
descending
|
Details | |
|---|---|---|---|---|---|---|---|---|
|
FLECS Marketplace
App marketplace for industrial automation |
612 001 00 | Integrated Safety FBD Editor for Safety PLC and Safety I/O | Technology | For safe automation applications up to SIL3 according to IEC 61508 and DIN EN ISO 13849 PLe, category 3/4 1002rd in all available editors | Installation as a package in the PLC programming system | CODESYS Standard SPS, EtherCAT, Sicherheits-SPS | to the product |
|
CODESYS SAFETY
Software for Safety PLCs |
612 001 00 | Integrated Safety FBD Editor for Safety PLC and Safety I/O | Technology | For safe automation applications up to SIL3 according to IEC 61508 and DIN EN ISO 13849 PLe, category 3/4 1002rd in all available editors | Installation as a package in the PLC programming system | CODESYS Standard SPS, EtherCAT, Sicherheits-SPS | to the product |
|
Modbus Master (TCP/RTU)
Communication protocol |
612 003 20 | Modbus TCP Master and Modbus RTU Master | Technology | Data exchange between a master and several slaves | Firmware | Kendrion Kuhnke control platform, Edge Computer | to the product |
|
CODESYS
SoftMotionLight |
612 000 75 | Operation of the Power State Machine, axis control in Profile Position Mode, Profile Velocity Mode, Homing Mode, extensive diagnostic options, configuration of user units in the unit editor | Technology | Single-axis or non-synchronised multi-axis movements | Firmware | Kuhnke PLC platforms | to the product |
|
CODESYS
Development System V3 |
612 000 10 | Project tree for structuring project configuration, e.g. to divide the entire application into objects and tasks, Configurator for integrating and describing various devices and fieldbus systems, Debugger, simulator and SoftPLC (as trial target system) | Technology | Programming PLCs fully compliant with the 3rd Edition of the IEC 61131-3 Standard in all available editors | Download on CODESYS Store International website | Windows 8.1 / 10 / 11 | to the product |
|
CODESYS
Runtime |
612 000 60 | Communication with the CODESYS Development System, Loading, management and execution of the application, Debugging of the application within CODESYS | Technology | Compact small controllers, Standard PLC systems for production machines, Panel controllers | Firmware | Kuhnke controller platforms | to the product |
|
CODESYS
HMI |
612 000 50 | Extensive options for designing visualizations, for example with many available elements, visualization styles, language switching, alarm management, recipes, and trend display | Technology | Visualizations for machines and plants | Firmware | Kuhnke Vico HMI devices | to the product |
|
|
CODESYS
SoftMotion |
612 000 70 | 3D CNC editor according to DIN 66025 (G code), Comprehensive interpolation functions from linear to spline interpolation, Support of virtual and logical axes | Technology | Pick&Place Application, CAM Application | Firmware | Kuhnke PLC platforms | to the product |
|
CODESYS
Motion CNC Robotics |
612 000 80 | Single or multi-axis movements with PLCopen motion POUs, Electronic CAM, Multidimensional CNC control, Multi axis robot controller with comfortable engineering | Technology | CNC application, Tripod robots, Palletizing robots | Firmware | Kuhnke PLC platforms | to the product |
|
|
OPC UA
Platform-independent standard access |
612 003 10 | Data exchange with the platform-independent standard OPC UA | Technology | Platform-independent vertical and horizontal communication | Firmware | Kuhnke control platform, Edge Computer | to the product |
|
CODESYS
Automation Server |
612 000 85 | Information on topology, controller status, current project, boot application and application parameters | Technology | Machinery and equipment | CODESYS Store, CODESYS Development System | Kuhnke control platform, Edge Computer | to the product |
|
|
System Interface
Dataexchange with CODESYS |
612 003 00 | Parameter browsing, synchronous reading and writing of data | Standard product | ARTI (Asynchronous Runtime Interface), GATEWAY, Simulation | Installer for Windows | Windows XP - 10 | to the product |
|
Motion Control Library
for CODESYS |
612.004.00 | Function blocks for the parameterization, positioning and diagnosis of the drive | Standard product | Positioning, pick & place application, format adjustment, Speed control, belt drives, Torque control, screw connection, pressure drive | Download | Available for CODESYS-based controls from Kendrion | to the product |
