Motorized Door Lock HS7722
HS7722 24 VDC
Kendrion's motorized door lock offers increased automation for use in many areas of everyday life. The combination of mechanical locking, motor drive, limit switches and electronic engineering is applied in our motorized door lock. The lock has more features than just locking the door. Closing the door with an adjustable, continuous force extends the life cycle of the seals. The lock is self-adjusting to maintain the lifetime of the seals. The big travel of up to 40 mm offers different end positions in the opening and closing process.
Technical details
| Description | Value |
|---|---|
| Usage of the locking | Automatic pull & push lock |
| Way of locking | Motorized locked |
| Nominal voltage | 24 V |
| Duty cycle | 10 % |
| Power consumption | 19 W |
| Max. static holding force | 400 N |
| Max. load force for electrical unlocking | 400 N |
| Connection | Male 15-pin D-sub-miniature connector |
| Snap-in function | Yes |
| Emergency opener | Yes |
| Operating temperature | 0 - 80 °C |
| Dimensions | 117 x 227 x 30 mm |
