Compact Rotary Solenoid of the CDR series

Simple and cost-efficient Design that can be modular adapted

The CDR has a simple design, allowing for cost-efficient production and customer-specific adaptation. Furthermore, due to the integrated permanent magnet, it is bistable, which effects currentless holding in the rotor end position. The ball bearing ensures wear-free use.

Standard variant available

The standard variant of the rotary solenoid line CDR is the CDR030 with a diameter of 30 mm and a rotation angle of 90°. Supply voltage, torque, and holding torque, as well as further technical data, can be seen in the table below.

Hall sensor and damper suitable for integration

Depending on the requirement, the CDR can be customized. Provision is made for the one or two-sided integration of hall sensors to ensure the function monitoring of the solenoid. Furthermore, dampers can be installed to reduce the noise when the rotary solenoid switches. Due to the modular design, more far-reaching adaptations can be realized with little development effort.





Added Values

  • Cost-efficient design
  • Low space requirements (diameter of 30mm)
  • High reliability

Technical Data

Alternative specifications on request

Operation bistable
Sizes 30 x 30 x 46mm
Supply voltage 24 V DC
Duty cycle 15%
Rotation angle 90°
Torque (POWER ON) 1.2 (Start) - 3.5 (max.) Ncm
Holding torque (POWER OFF) 3.2 Ncm
Protection class IP 30
Environmental temperature from -10 to +40°
Hall sensor (optional) minus switching, 5-30 V DC, max 30 mA
Comment internal stoppers available
