Kuhnke FIO Controller 116
SM WV (OPC UA)
694 520 16 001
The Kuhnke FIO Controller 116 is PLC based on i.MX6 with integrated CODESYS PLC with integrated CODESYS PLC, SoftMotion option with PLCopen blocks for master/slave movements and CAM editor. It is able to exchange data with other systems via industrial Ethernet and RS232. In addition, a built-in SD-card slot and a USB-interface allow local storage of process data. An interrupt input allows realizing fastest possible reactions on specific process events. As far as mechanic properties and form factor are concerned, the controller matches the FIO I/O modules, which can be attached directly to form a mechanically and electrically homogenous unit. Using an additional extender module also the control of remote EtherCAT slaves is possible. It can be easily integrated by the number of interfaces (Industrial Ethernet, RS232, CAN) and supported systems into existing control concepts.
- Fanless ARM processor technology
- To be extended with FIO modules
- CODESYS V3 with EtherCAT®
- CODESYS SoftMotion
Technical details
| Description | Value |
|---|---|
| Configuration | CODESYS PLC + SoftMotion |
| Function | Modular PLC |
| Model | Control cabinet modul |
| Product status | Standard product |
| Processor | i.MX6 SoloX Freescale 1 GHz |
| Operating system | RT Linux |
| Software | CODESYS V3 |
| Software options | Softmotion, Modbus RTU, OPC UA Server, WebVisu |
| Main memory | 128 |
| Non-volatile memory | 128 kByte |
| Data memory | SD card |
| Drive | Flash memory |
| Interfaces | LAN, USB, CAN, RS-232, EtherCAT-E-Bus |
| Digital I/Os (integrated) | 1DI, 1 ms |
| Field bus interfaces | EtherCAT, CANopen, Modbus RTU and TCP |
| Modular expansion | Expandable with FIO I/O modules |
| Housing material | Aluminium frame, plastic housing |
| Dimensions (W x H x D) | 25 x 120 x 90 mm |
| IP-Protection Class | IP20 |
| Supply voltage | 24 V DC (-15% ... +20%) |
